Hey guys! Ever wondered about all the little bits and pieces that make up your trusty Starrett combination square? Well, you've come to the right place. Let's dive deep into understanding each part, so you can keep your tool in tip-top shape and get the most out of it. Combination squares are indispensable tools for woodworkers, metalworkers, and DIY enthusiasts alike. Renowned for their precision and versatility, Starrett combination squares stand out as a top choice. Knowing each component not only aids in maintenance but also enhances your understanding of how to use this tool effectively. So, grab your square, and let's get started!

Understanding the Blade (or Rule)

Let's kick things off with the blade, also known as the rule. This is the long, graduated metal strip that forms the backbone of your combination square. Understanding the blade is crucial because it's the primary measuring surface. Without a properly calibrated and maintained blade, the entire tool loses its accuracy. The blade is typically made of hardened steel to resist wear and maintain its straightness over time. High-quality steel ensures that the graduations remain accurate, even with frequent use. Different lengths are available, usually ranging from 6 inches to 24 inches, catering to various project requirements. Longer blades are useful for larger workpieces, while shorter blades are more convenient for detailed tasks.

The graduations on the blade are laser-etched or precision-machined, offering clear and precise markings. These markings are crucial for accurate measurements. Common scales include inches (with subdivisions like 1/8, 1/16, 1/32, and 1/64) and millimeters. Some blades feature both imperial and metric scales, providing versatility for different measurement systems. Ensure the graduations are easy to read and not worn out, as this affects the accuracy of your measurements. Proper cleaning and storage can help maintain the legibility of the markings. Always wipe down the blade after use to remove any debris or moisture that could cause corrosion. Storing the blade in a dry environment will also prevent rust.

Blades can sometimes get damaged or bent. If you notice any bends, nicks, or significant wear, it's time to consider a replacement. Using a damaged blade can lead to inaccurate measurements and compromise the quality of your work. Replacement blades are available from Starrett and other suppliers, ensuring you can keep your combination square in perfect working order. When replacing a blade, make sure to choose one that is compatible with your specific model of combination square. The dimensions and mounting mechanism must match to ensure proper fit and function. It's also a good idea to check the calibration of the new blade against a known standard to verify its accuracy.

The Square Head: Your Right-Angle Master

Next up is the square head, which is designed to slide along the blade and lock into position. This is where the magic happens for creating accurate 90-degree angles. The square head's precision is paramount, as it directly influences the accuracy of your right-angle measurements. Typically made from cast iron or hardened steel, the square head needs to be robust enough to withstand regular use and maintain its shape over time. The quality of the material and the precision of the machining are critical factors in ensuring the square head's accuracy and durability.

The square head features a precision-ground 90-degree face, used to check and mark right angles. This face must be perfectly square to the blade to ensure accurate results. Over time, the square head can lose its accuracy due to wear, impact, or improper storage. Regularly check the squareness of the head using a reliable reference, such as a precision square or a granite surface plate. If you find any discrepancies, the square head may need to be adjusted or replaced. The square head also incorporates a spirit level, which is a small vial filled with liquid and an air bubble. This level is used to verify that a surface is perfectly horizontal or vertical. The accuracy of the spirit level is crucial for applications where levelness is critical. Check the level periodically to ensure it is properly calibrated. If the bubble is off-center when the square head is placed on a known level surface, the level may need to be adjusted or replaced.

Additionally, the square head usually includes a scribing point. This small, hardened steel point is used for marking lines parallel to the edge of a workpiece. The scribing point is particularly useful for transferring measurements or creating layout lines. Ensure the scribing point is sharp and free from damage to achieve clean, accurate lines. Sharpen the point as needed using a fine file or honing stone. A locking mechanism, typically a thumbscrew or lever, secures the square head to the blade at the desired position. The locking mechanism must provide a firm, reliable hold to prevent slippage during use. Check the locking mechanism regularly to ensure it is functioning properly. If the square head slips or moves after being locked, the locking mechanism may need to be tightened or repaired.

Protractor Head: Angles Made Easy

Now, let's talk about the protractor head. This attachment allows you to measure and mark angles other than 90 degrees. It's a game-changer for complex projects. The protractor head typically features a rotating turret with degree markings, allowing you to set the desired angle. High-quality protractor heads offer precise, laser-etched markings for easy reading and accurate angle setting. The turret should rotate smoothly and lock securely in place to maintain the set angle during use. The protractor head is invaluable for tasks such as cutting miters, bevels, and other angled joints. Its ability to accurately measure and transfer angles makes it an essential tool for woodworking, metalworking, and construction projects. Whether you're building a picture frame or fabricating a complex metal structure, the protractor head can help you achieve precise, professional results.

The protractor head usually includes a locking mechanism to secure the turret at the desired angle. This mechanism must provide a firm, reliable hold to prevent the turret from slipping during use. Check the locking mechanism regularly to ensure it is functioning properly. If the turret moves after being locked, the locking mechanism may need to be tightened or repaired. The accuracy of the protractor head is critical for achieving precise angled cuts and measurements. Periodically check the accuracy of the protractor head using a reliable reference, such as a precision protractor or angle gauge. If you find any discrepancies, the protractor head may need to be adjusted or replaced. Proper maintenance and care can help extend the life of your protractor head and ensure its continued accuracy.

Center Head: Finding the Middle Ground

The center head is another handy attachment. It helps you find the center of round stock or discs quickly and accurately. Finding the center has never been easier. The center head typically consists of two arms that form a V-shape, with the blade running along the center of the V. When the arms are placed against the circumference of a round object, the blade indicates the center point. The accuracy of the center head depends on the precision of its V-shaped arms and the alignment of the blade. Ensure the arms are properly aligned and free from damage to achieve accurate center measurements. The center head is particularly useful for tasks such as drilling holes in the center of round stock or laying out circles and arcs. Its ability to quickly and accurately locate the center point saves time and effort compared to traditional methods. Whether you're a woodworker creating decorative turnings or a metalworker fabricating precision parts, the center head can help you achieve accurate, professional results.

The center head is designed to slide along the blade and lock into position. The locking mechanism must provide a firm, reliable hold to prevent slippage during use. Check the locking mechanism regularly to ensure it is functioning properly. If the center head slips or moves after being locked, the locking mechanism may need to be tightened or repaired. Proper maintenance and care can help extend the life of your center head and ensure its continued accuracy. Clean the arms and blade regularly to remove any debris or contaminants that could affect its performance. Store the center head in a safe place to prevent damage to its precision components.

The Lock Nut or Thumbscrew: Keeping it All Together

Let's not forget the lock nut or thumbscrew. This little guy is essential for securing the heads to the blade. It's the unsung hero of the combination square. The lock nut or thumbscrew must provide a firm, reliable hold to prevent the heads from slipping during use. Check the lock nut or thumbscrew regularly to ensure it is functioning properly. If the heads slip or move after being locked, the lock nut or thumbscrew may need to be tightened or replaced. The lock nut or thumbscrew is typically made from hardened steel or brass to resist wear and corrosion. High-quality materials and precision machining ensure that the lock nut or thumbscrew provides a secure, long-lasting hold. Proper maintenance and care can help extend the life of your lock nut or thumbscrew and ensure its continued reliability. Avoid over-tightening the lock nut or thumbscrew, as this can damage the threads or strip the head. Use only the amount of force necessary to securely lock the heads in place. If the lock nut or thumbscrew becomes damaged or worn, replace it immediately to prevent slippage and maintain the accuracy of your combination square.

Spirit Level and Scribe

Many square heads also incorporate a spirit level for finding horizontal and vertical planes, and a scribe for marking. These additions boost the square's versatility. The spirit level is a small vial filled with liquid and an air bubble. When the bubble is centered between the lines on the vial, it indicates that the surface is level or plumb. The accuracy of the spirit level is crucial for applications where levelness is critical. Check the level periodically to ensure it is properly calibrated. If the bubble is off-center when the square head is placed on a known level surface, the level may need to be adjusted or replaced. The scribe is a small, hardened steel point used for marking lines parallel to the edge of a workpiece. The scribe is particularly useful for transferring measurements or creating layout lines. Ensure the scribe is sharp and free from damage to achieve clean, accurate lines. Sharpen the point as needed using a fine file or honing stone.

Maintaining Your Starrett Combination Square

To keep your Starrett combination square in top condition, regular maintenance is key. A little care goes a long way. Always clean the blade and heads after use to remove any dirt, debris, or moisture. Use a clean, dry cloth to wipe down the surfaces. For stubborn residue, you can use a mild solvent or cleaner specifically designed for tools. Avoid using abrasive cleaners or scouring pads, as these can damage the finish and markings. Regularly check the accuracy of the square and protractor heads using a reliable reference. If you find any discrepancies, the heads may need to be adjusted or replaced. Store your combination square in a safe, dry place to prevent damage and corrosion. A tool chest or case is ideal for protecting the square from impacts and environmental factors. Apply a light coat of oil to the blade and heads periodically to prevent rust. Use a high-quality machine oil or protectant specifically designed for tools. Avoid using excessive amounts of oil, as this can attract dirt and debris. Inspect the locking mechanisms regularly to ensure they are functioning properly. Tighten any loose screws or bolts, and replace any worn or damaged parts. By following these simple maintenance tips, you can keep your Starrett combination square in top condition and ensure its accuracy and reliability for years to come.

Conclusion

So there you have it! A comprehensive look at the parts of a Starrett combination square. Knowing each component and its function will not only help you maintain your tool but also improve the accuracy of your work. Keep your square clean, calibrated, and in good repair, and it will serve you well for years to come. Happy woodworking (or metalworking)! Maintaining your Starrett combination square involves simple steps such as regular cleaning, accuracy checks, and proper storage. With these practices, your tool will remain reliable and precise, ready for any project that comes your way.
